KEDBROOKE 1GANG 1WAY SWITCH KBV3011

1. Turn Off Power: Before beginning any electrical work, turn off the power at the circuit breaker to ensure safety.
2. Identify Wires: You’ll have three wires coming from your electrical supply:
   • Live (L): Usually brown or red in color.
   • Neutral (N): Usually blue or black in color.
   • Earth (E): Usually green/yellow in color.
3. Switch Socket Terminals: The KBV3011 unit will have terminals labeled for these connections:
   • L (Live): This is where the live wire (brown) from your electrical supply connects.
   • N (Neutral): Connect the neutral wire (blue) from your electrical supply.
   • E (Earth): Connect the earth wire (green/yellow) from your electrical supply.
4. Wiring Process:
   • Live (L): Connect the live wire (brown) from your electrical supply to the L terminal of the switch socket.
   • Neutral (N): Connect the neutral wire (blue) from your electrical supply to the N terminal of the switch socket.
   • Earth (E): Connect the earth wire (green/yellow) from your electrical supply to the E terminal of the switch socket.
5. Testing: Once all connections are securely made, double-check everything before restoring power at the circuit breaker. Test the switch socket to ensure it functions correctly.
6. Secure and Close: Secure the switch socket unit into the wall box using the screws provided. Install the faceplate to cover the unit.

Important Notes:

• Ensure all connections are tight and secure to prevent electrical hazards.
• If you are unsure about any part of the installation, seek assistance from a qualified electrician.
• Follow local electrical codes and regulations strictly.

By following these steps, you should be able to correctly wire the Kedbrooke 1 Gang 1 Way Switch Socket (KBV3011) using the appropriate wiring points for live, neutral, and earth connections.
